Concealed Cup Hinge Metalla 50 A 110° half overlay, nickel
Item code: L-H5011
Item code copied!
Concealed Cup Hinge Metalla 50 A 110° half overlay, nickel
Item code: L-H5011
Item code copied!
€0.50
pcs
(with VAT)
Item in stock.
Delivery time: 1-3 business days*
Half overlay hinge
Technical specifications:
- Side adjustment: ±2 mm
- Height adjustment: ±2 mm
- Depth adjustment: -1.5 mm to +4.5 mm
Data sheet
| Brand | Häfele |
|---|---|
| Opening angle, ° | 110 |
| Type of facade | Half |
| Door material | Board |
| Comfort functions opening/closing | Su pritraukimu |
| Cup depth, mm | 12 |
| Cup width, mm | 35 |
| Material | steel |
| Series | Metalla 50 |
| Colour | steel |
| Screw drilling dimensions, mm | 48/6 |
| Door thickness, mm | 14-24 |
| Vendor item no. | 311.90.021 |
| Installation | Slide-on/A |
