Concealed Cup Hinge Metalla 50 A 110° inset, nickel
Item code: L-H5012
Item code copied!
Concealed Cup Hinge Metalla 50 A 110° inset, nickel
Item code: L-H5012
Item code copied!
€0.50
pcs
(with VAT)
Item in stock.
Delivery time: 1-3 business days*
Inset mounted hinge
Technical specifications:
- Side adjustment: ±2 mm
- Height adjustment: ±2 mm
- Depth adjustment: -1.5 mm to +4.5 mm
Data sheet
| Brand | Häfele |
|---|---|
| Opening angle, ° | 110 |
| Type of facade | Internal |
| Door material | Board |
| Comfort functions opening/closing | Su pritraukimu |
| Cup depth, mm | 12 |
| Cup width, mm | 35 |
| Material | steel |
| Series | Metalla 50 |
| Colour | steel |
| Screw drilling dimensions, mm | 48/6 |
| Door thickness, mm | 14-24 |
| Vendor item no. | 311.90.022 |
| Installation | Slide-on/A |
Product photos are for illustrative purposes only. The actual appearance, colors, configuration, dimensions, and other features of the products may differ from those shown in the images. For accurate information, please refer to the product descriptions, technical specifications, instructions, and provided links.
