Wardrobe lift, Häfele Dresscode
Item code: X80522760
Item code copied!
€129.49
set
(with VAT)
Item is not in stock and is available for special order only.
Delivery time: 7-15 business days*
Wardrobe lift, designed for tall furniture panels or DressCode aluminium profile system
Technical specifications:
- Simple mounting removal or position adjustment thanks to special foldable brackets
- Adjustable width, suitable for cabinets 440-610 or 600-1000 mm wide
- Integrated soft-close mechanism upwards
Mounting method:
- Plates with foldable brackets are inserted into Ø5 mm drill holes
- Mechanism is fixed onto plates
*Note: table of dimensions indicates internal cabinet module width
DressCode profile system and wardrobe accessories mounting (video)
For mounting in DressCode aluminium profile system crosspieces (4 pcs) are additionally ordered
Set includes:
- Mounting plates with foldable brackets – 2 pcs
- Mechanisms with elbows – 2 pcs
- Adjustable-length tube – 1 pc
- Pull rod – 1 pc
- Tilt plates used to mount pantograph close to back wall – 2 pcs
- Fixings
Data sheet
| Brand | Häfele |
|---|---|
| Height, mm | 850 |
| Material | Steel/Plastic |
| Series | DressCode |
| Colour | white |
| Load capacity, kg | 10 |
| External module width, mm | 440-610 |
| Vendor item no. | 805.22.760 |
