Sliding door fitting, Slido Flat 60 FB, flush, set
Item code: X40050104
Item code copied!
Sliding door fitting, Slido Flat 60 FB, flush, set
Item code: X40050104
Item code copied!
€978.50
set
(with VAT)
Item is not in stock and is available for special order only.
Delivery time: 7-15 business days*
Single-plane exterior door system
Technical specifications:
- Suitable for panel or aluminium profile doors
- With soft-close mechanism
- Door thickness (with handle): max. 16–43 mm
- Recommended weight per door panel:
- 2-door systems – 60 kg
- 3-door systems – centre panel up to 100 kg, side panels up to 45 kg
- Door panel width:
- 2-door systems – 890–1800 mm
- 3-door systems – 1300–1800 mm
- Anti-derailment protection
- Height adjustment: -4 to +5 mm
- Top track routed in
- Bottom track routed in
- One set – for 1 door panel
For two-door wardrobes: (A, B, C, G, H)
- X40050101 left-opening
- X40050102 right-opening
For three-door wardrobes: (D, E, F)
- X40050103 left-opening
- X40050104 right-opening
Sold separately:
- Track set
Data sheet
| Brand | Häfele |
|---|---|
| Load capacity, kg | 60 |
| Side | right |
| Supplied with | 1 running gear, top, with soft closing mechanism, 1 running gear, bottom, 1 stop, top, 1 stop, bottom |
| Vendor item no. | 400.50.104 |
